LUCAS 3 CPR Chest Compression System

LUCAS 3.1 CPR Chest Compression System

The LUCAS® 3.1 Chest Compression System is designed to support high-quality, consistent CPR during cardiac arrest response. Built for emergency medical teams, clinical settings and trained responders, LUCAS 3.1 delivers automated chest compressions at a consistent rate and depth, helping reduce rescuer fatigue and supporting continuous CPR during treatment, movement and transport.

With configurable compression settings, the LUCAS 3.1 can be adapted to suit local protocols. Compression rates can be set at 102, 111 or 120 compressions per minute, while the system maintains a compression depth of 45 to 53 mm. The device also includes ventilation alerts, adjustable pause settings and an audible CPR timer to help teams manage CPR cycles effectively.

The LUCAS 3.1 features a simple user interface and is designed for quick deployment in time-critical situations. AutoFit and QuickFit functionality helps position the piston efficiently, while optional pressure pad release allows chest rise during ventilation. Data connectivity through Wi-Fi, LIFENET® System and CODE-STAT™ Data Review Software can also support post-event reporting and quality review where available.

Key Features

• Automated mechanical chest compressions for consistent CPR delivery
• Adjustable compression rate: 102, 111 or 120 compressions per minute
• Compression depth of 45 to 53 mm during operation
• Configurable ventilation alerts, pause length and compression count
• Audible CPR timer adjustable from 1 to 15 minutes
• AutoFit and QuickFit functionality for efficient piston positioning
• Optional pressure pad release to support ventilation
• Wi-Fi connectivity for compatible data review and reporting systems
• Designed to support emergency response teams during treatment, transfer and transport

What’s Included

Every LUCAS 3.1 Chest Compression System, Stryker part number 99576-000065, is supplied as a complete operational kit.

Included in the box:

• 1 x LUCAS 3.1 Chest Compression System
• 1 x Battery
• 1 x Carrying bag
• 1 x Stabilisation strap
• 1 x Patient wrist straps
• 2 x Disposable suction cups
• 1 x Instructions for Use

Please note: the LUCAS 3.1 is supplied with a carrying bag as standard. The hard shell carry case shown as an accessory on this page is a separate upgrade and is sold individually.

Necessary Accessory
LUCAS 3.1 Chest Compression System Auxiliary Power Supply

The auxiliary power supply is recommended for powering the LUCAS 3.1 during extended use, charging and operational readiness. It helps support continuous availability of the device when used in clinical, ambulance or emergency response environments.

Recommended LUCAS 3.1 Accessories

LUCAS 3.1 Chest Compression System Battery

A replacement or spare battery helps ensure your LUCAS 3.1 system remains ready for use. Keeping an additional battery available is recommended for emergency response teams, ambulance services and clinical locations where the device may be used regularly.

LUCAS 3.1 Chest Compression System Carry Case

The optional hard shell carry case provides additional protection for the LUCAS 3.1 during storage and transport. This is an upgraded case and is sold separately from the standard LUCAS 3.1 system kit.

For advice on purchasing the LUCAS 3.1 Chest Compression System or selecting the correct accessories, contact the Risk Assessment Products team.

lucas3-v.1_brochure

*Please note that the backpack is sold separately.*
